Product Summary

The MCIMX257DJM4A multimedia applications processor has the right mix of high performance, low power, and integration to support the growing needs of the industrial and general embedded markets. The MCIMX257DJM4A is suitable for a wide range of applications, including the following: Graphical remote controls, Human Machine Interface (HMI), Residential and commercial control panels and Residential gateway (smart metering).

Parametrics

MCIMX257DJM4A absolute maximum ratings: (1)Supply voltage QVDD: –0.5 to 1.52 V; (2)Supply voltage (level shift i/o) VDDIOmax: –0.5 to 3.6 V; (3)ESD damage immunity: Human body model (HBM) 2500 V; (4)ESD damage immunity: Charge device model (CDM), 400 V; (5)ESD damage immunity: Machine model (MM) 200 V; (6)Input voltage range VImax: –0.5 to NVDD + 0.3 V; (7)Storage temperature range Tstorage: –40 to 105℃.

Features

MCIMX257DJM4A features: (1)Advanced power management; (2)Multimedia powerhouse; (3)128 Kbytes on-chip SRAM; (4)Interface flexibility; (5)Increased security; (6)On-chip PHY; (7)Fast Ethernet; (8)i.MX25 only supports Little Endian mode.

Diagrams

MCIMX257DJM4A block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
MCIMX257DJM4A
MCIMX257DJM4A

Freescale Semiconductor

Processors - Application Specialized IMX25 1.2 COMM

Data Sheet

0-1: $5.51
1-25: $5.35
25-50: $5.18
50-100: $4.46
