Product Summary

The Silicon Image SII3114CTU is a single-chip solution for a PCI to Serial ATA controller. It accepts host commands through the PCI bus, processes them, and transfers data between the host and Serial ATA devices. It can be used to control four independent Serial ATA channels. Each channel has its own Serial ATA bus and will support one Serial ATA device. The SII3114CTU supports a 32-bit 66 MHz PCI bus and the Serial ATA Generation 1 transfer rate of 1.5 Gbit/s (150 MB/s).

Parametrics

Absolute maximum ratings: (1)I/O Supply Voltage: 4.0 V; (2)Digital, PLL, Analog and Oscillator Supply Power: 2.15 V; (3)Input Voltage for PCI signals: -0.3 ~ 6.0 V; (4)Input Voltage for Non-PCI signals: -0.3 ~ VDDO+0.3 V; (5)VCLKI_IN Input Voltage for CLKI: -0.3 ~ VDDX+0.3 V; (6)DC Output Current: 16 mA; (7)Thermal Resistance (Junction to Ambient): 32.6 ℃/W; (8)Storage Temperature: -65 ~ 150 ℃.

Features

Features: (1)Standalone PCI to Serial ATA host controller chip; (2)Compliant with PCI Specification, revision 2.3; (3)Compliant with Programming Interface for Bus Master IDE Controller, revision 1.0; (4)Driver support for Windows 98, Windows Millennium, Windows NT 4.0, Windows 2000, XP, Windows 2003, Netware 5.1, 6.0, 6.5, Red Hat Linux 8.0, 9.0, SuSE Linux 8.1, 8.2 and United Linux 1.0; (5)Supports up to 4Mbit external Flash or EPROM for BIOS expansion; (6)Supports an external EEPROM, flash, or EPROM for programmable device ID, subsystem vendor ID, subsystem product ID, and PCI sub-class code.

Diagrams
