Product Summary

The DS18S20+ is a Digital Thermometer. It provides 9–bit temperature readings which indicate the temperature of the device.

Parametrics

Absolute maximum ratings: (1)Supply Voltage:3.0V to 5.5V; (2)Data Pin:-0.3V to VDD; (3)Logic 1:2.2V to VDD+0.3V; (4)Logic 0:-0.3V to +0.8V.

Features

Features: (1)Unique 1–Wire interface requires only one port pin for communication; (2)Multidrop capability simplifies distributed temperature sensing applications; (3)Requires no external components; (4)Can be powered from data line.Power supply range is 3.0V to 5.5V; (5)Zero standby power required; (6)Measures temperatures from –55℃ to +125℃.; (7)±0.5℃ accuracy from –10℃ to +85℃; (8)Temperature is read as a 9–bit digital value; (9)Converts temperature to digital word in 750 ms (max.).

Diagrams

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
DS18S20+
DS18S20+

Maxim Integrated Products

Board Mount Temperature Sensors Prgmble Resolution 1-Wire Parasite Pwr

Data Sheet

0-1: $3.40
1-25: $2.28
25-50: $1.65
50-100: $1.63
DS18S20+PAR
DS18S20+PAR

Maxim Integrated Products

Board Mount Temperature Sensors Prgmble Resolution 1-Wire Parasite Pwr

Data Sheet

0-1: $3.42
1-25: $2.28
25-50: $1.65
50-100: $1.63
DS18S20+T&R
DS18S20+T&R

Maxim Integrated Products

Board Mount Temperature Sensors Prgmble Resolution 1-Wire Parasite Pwr

Data Sheet

0-1: $3.11
1-25: $2.35
25-50: $2.09
50-100: $2.05
